I failed emissions help!!!!
10-25-2008, 07:13 PM
#1
I failed emissions help!!!!
My emission test on my 95 rs integra failed. all of the ASM readings failed but passed all curb idle. I had a stuck open pcv valve, and inspected my rusty *** catalytic converter and it looked pretty clogged and white inside. My car has a short ram intake with a brand new filter, and a performance axle back exhaust. I fueled up full tank with Ultra 94 and added a bottle of Octane booser prior to doing the emission test. I probably should have not done that huh? I NEED ADVICE, I can't afford to keep doing emission tests, suggestions will be greatly appreciated and also some useful tidbits.
10-25-2008, 09:22 PM
#4
There's plenty to do outside my room but I choose not to!
iTrader: (2)
Join Date: Aug 2003
Location: The Hammer!
Posts: 8,166
---- it I'm not gonna say it again and again. I'm starting to sound like a broken record or a parrot.
Search this section and you'll find some answers.
Search this section and you'll find some answers.
10-25-2008, 10:41 PM
#8
Guest
Posts: n/a
Everybody is nice here but the people new to the boards need to understand that it's a waste to create similar threads or ask the same questions over and over again. We sure can help you out but help yourself too. Understandable that you're new to the "forum thing" but are you new to computers or internet?
Here are some threads that give you more info on Emission test fails. No surprises all these threads pressure on using methyl hydrate.
https://www.torontointegras.ca/forum...light=Emission
https://www.torontointegras.ca/forum...light=Emission
https://www.torontointegras.ca/forum...light=Emission
And this one tells you to search.
https://www.torontointegras.ca/forum...light=Emission
Good luck with your emissions and enjoy your stay on the board.
Here are some threads that give you more info on Emission test fails. No surprises all these threads pressure on using methyl hydrate.
https://www.torontointegras.ca/forum...light=Emission
https://www.torontointegras.ca/forum...light=Emission
https://www.torontointegras.ca/forum...light=Emission
And this one tells you to search.
https://www.torontointegras.ca/forum...light=Emission
Good luck with your emissions and enjoy your stay on the board.
10-27-2008, 10:25 AM
#11
Junior Member
Join Date: May 2008
Location: Hamilton
Posts: 343
just do the work once..copy it into a word doc and paste it up everytime someone asks ..
If you dont wanna deal with constantly retesting.. PM me.. i have the answer..
Last edited by Fieldzy09; 10-27-2008 at 10:28 AM.
10-27-2008, 12:17 PM
#12
Junior Member
Join Date: Jun 2008
Location: Ontario
Posts: 450
You don't have the answer, you have a work around :P
10-27-2008, 02:52 PM
#13
Member
Join Date: Apr 2008
Location: Etobicoke
Posts: 525
put a litre of methyl hydrate in your tank with some gas and drive for about 10-15 min. should clean it up. no sense in putting someones business a risk when it could just cost you $5.
the old engine on my beater was burning almost a litre of oil a day. i put in some methyl hydrate and drove for 20min. i had an old cat, plugs and wires on top of that. it still passed.
the old engine on my beater was burning almost a litre of oil a day. i put in some methyl hydrate and drove for 20min. i had an old cat, plugs and wires on top of that. it still passed.
10-31-2008, 07:44 AM
#15
First Test without Methyl Hydrate running on Ultra94 gas with octane booster:
ASM test
HC ppm 68 limit 120Fail
CO% 0.38limit 0.65Fail
NO ppm 526limit 1166Fail
Second test with 1 litre of Methyl Hydrate running on the same gas:
ASM test
HC ppm 68limit 119Fail
CO% 0.38limit 0.53Fail
NO ppm 526limit 840Fail
ASM test
HC ppm 68 limit 120Fail
CO% 0.38limit 0.65Fail
NO ppm 526limit 1166Fail
Second test with 1 litre of Methyl Hydrate running on the same gas:
ASM test
HC ppm 68limit 119Fail
CO% 0.38limit 0.53Fail
NO ppm 526limit 840Fail
11-01-2008, 10:07 PM
#20
yea i picked up a brand new direct-fit cat (not a high flow) and also a new O2 sensor while I am at it hehehe... crossing my fingers for monday is test day. I will definitely post numbers after the test. and NOFEAR, i tried the methyl hydrate and did not work.
11-02-2008, 10:40 PM
#22
Junior Member
Join Date: Jan 2008
Location: niagara region
Posts: 349
the whole methyl hydrate trick doesn't work on all cars, every car and make is all different. they all operate different and have totally different readings.
alot of the times the methyl hydrate can increase engine temp in some cars and cause you to fail the NOX on the ASM.
if the cat is ---- swap it and O2 why not while your at it. the numbers looks like to me is just the cat. best to do is after installed take it out for a decent drive cause sometimes it wont pass right away if you put it on and just test it. it is best to let it clear out anything bad in the exhaust and ---- first.
i dont know how many times i fail cars and the people are just so ignorant and they dont listen and just go around picking up myths from people to try and make there cars pass. like the emissions "guarranteed to pass". people run in grab a bottle pour it in the tank and bring it in for a test. then they fail and wonder why, well if they stopped and thought to read the box it clearly reads to fill the tank to one botttle of the formula and drive the tank out and refill again and i think clear that tank out refill just gas then test.
everyone thinks its some magic syrum or something, same with the methyl hydrate. if your car fails its cause ts got a problem, and if its something you wanna fix up stop wth the stupid band-aid fixes cause its not fixing the real problem.
pretty much guaranteed to get your pass tomorrow bud.
alot of the times the methyl hydrate can increase engine temp in some cars and cause you to fail the NOX on the ASM.
if the cat is ---- swap it and O2 why not while your at it. the numbers looks like to me is just the cat. best to do is after installed take it out for a decent drive cause sometimes it wont pass right away if you put it on and just test it. it is best to let it clear out anything bad in the exhaust and ---- first.
i dont know how many times i fail cars and the people are just so ignorant and they dont listen and just go around picking up myths from people to try and make there cars pass. like the emissions "guarranteed to pass". people run in grab a bottle pour it in the tank and bring it in for a test. then they fail and wonder why, well if they stopped and thought to read the box it clearly reads to fill the tank to one botttle of the formula and drive the tank out and refill again and i think clear that tank out refill just gas then test.
everyone thinks its some magic syrum or something, same with the methyl hydrate. if your car fails its cause ts got a problem, and if its something you wanna fix up stop wth the stupid band-aid fixes cause its not fixing the real problem.
pretty much guaranteed to get your pass tomorrow bud.
11-03-2008, 09:24 PM
#24
Junior Member
Join Date: Jan 2008
Location: niagara region
Posts: 349
wtf is a bypass?
u mean under the table etest?
its stupid especially if its a modified car and a cop thats suspicious pulls you over, if he wanted to he could have it tested on the side of the road.
plus you never figure out the real reason with whats up with your car and you can do further damage. or could need no more than just and oil change to pass. wouldn't that be a **** off if it was only like a $25 repair or service to make it pass?
best thing to always do is a fresh oil change and plugs then go for a test. always have and never failed.
11-04-2008, 06:01 PM
#25
ok I went for the test with a new cat and o2 sensor and failed one part which is NO ppm limit is 526 and read 823. Everything else is PASS with flying colors. Before I went for the test, I took the car for a drive from mississauga to scarborough and to toronto for the test. That is after the cat and 02 sensor just got installed. Before I went for the first E-test I had all spark plugs changed to NGK iridiums, new NGK spark plug wires, pcv valve, air filter, and fresh oil change. I never checked for proper timing though, and that is what I am thinking. Maybe there is too much spark advance and it is running lean... Can anybody shed some light into this as I am baffled.
11-04-2008, 06:23 PM
#26
Member
Join Date: Apr 2003
Posts: 563
that is the problem with aftermarket converters. they don't clean up NOx to well even when they are new.
since you changed the 2 major components that effects the tail pipe emissions already the next trick to get it to pass guaranteed this time around is to back the timing off enough so that it will pass. the stock base timing for a integra is about 16deg BTDC. set it to around 10deg and go for a retest. it will pass this time around.
since you changed the 2 major components that effects the tail pipe emissions already the next trick to get it to pass guaranteed this time around is to back the timing off enough so that it will pass. the stock base timing for a integra is about 16deg BTDC. set it to around 10deg and go for a retest. it will pass this time around.
ok I went for the test with a new cat and o2 sensor and failed one part which is NO ppm limit is 526 and read 823. Everything else is PASS with flying colors. Before I went for the test, I took the car for a drive from mississauga to scarborough and to toronto for the test. That is after the cat and 02 sensor just got installed. Before I went for the first E-test I had all spark plugs changed to NGK iridiums, new NGK spark plug wires, pcv valve, air filter, and fresh oil change. I never checked for proper timing though, and that is what I am thinking. Maybe there is too much spark advance and it is running lean... Can anybody shed some light into this as I am baffled.
11-04-2008, 07:27 PM
#28
Junior Member
Join Date: Jun 2008
Location: Ontario
Posts: 450
ok I went for the test with a new cat and o2 sensor and failed one part which is NO ppm limit is 526 and read 823. Everything else is PASS with flying colors. Before I went for the test, I took the car for a drive from mississauga to scarborough and to toronto for the test. That is after the cat and 02 sensor just got installed. Before I went for the first E-test I had all spark plugs changed to NGK iridiums, new NGK spark plug wires, pcv valve, air filter, and fresh oil change. I never checked for proper timing though, and that is what I am thinking. Maybe there is too much spark advance and it is running lean... Can anybody shed some light into this as I am baffled.
Is this an auto or stick.. Autos have an EGR that could cause higher NOx if its not working correctly.
11-05-2008, 12:47 AM
#30
It could be leaning out a bit because of where your timing is set and bumping up your nox because of the combustion temp but next time you go after you retard your timing go to crappy tire and tell them that engine is a b20 and its not supposed to be in the car they can run it as a "hot rod" which will bump all of your numbers up on hc , co, and nox. This is what they did for me just a few months back and most people there dont know ---- about honda's anyways.
11-05-2008, 06:31 PM
#32
no how could you for all they know you blew your engine and put in a new one over night its your car you can do what you want. You dont tell your insurance when you take out a d15 and swap a b20V turbo you just pay for the ---- engine on insurance and take the risk. But besides that I used to get fake etests because when i ran a gsr in the car i had a hollow cat but after i took it out to build it i swaped to a b20 just to have a car to drive and put on a magnaflow high performance cat headers and 2.5 pollished stainless all the way back and I took the chance ran the car legit at crappy tire and it passed with flying colours and they did bump the numbers up because the guy was cool and said ya we can run it as a hot rod because that motor does't belong in the car and i took that same sheet to the ministry with the 2.0 on paper and here i am today with my sticker a happy man. Oh and don't quote me but dont the b20's and the non vtec integra engines have the same looking valve cover anyways? just it says b18 or b20 on the tag at the front of the block just smudge some grease over it they wont know ---- lol.
Last edited by black_ac_gsr; 11-05-2008 at 06:40 PM.
11-12-2008, 04:35 PM
#34
Time to become a Premier Member!
Join Date: Mar 2003
Location: www.tittypalace.com
Posts: 3,994
no how could you for all they know you blew your engine and put in a new one over night its your car you can do what you want. You dont tell your insurance when you take out a d15 and swap a b20V turbo you just pay for the ---- engine on insurance and take the risk. But besides that I used to get fake etests because when i ran a gsr in the car i had a hollow cat but after i took it out to build it i swaped to a b20 just to have a car to drive and put on a magnaflow high performance cat headers and 2.5 pollished stainless all the way back and I took the chance ran the car legit at crappy tire and it passed with flying colours and they did bump the numbers up because the guy was cool and said ya we can run it as a hot rod because that motor does't belong in the car and i took that same sheet to the ministry with the 2.0 on paper and here i am today with my sticker a happy man. Oh and don't quote me but dont the b20's and the non vtec integra engines have the same looking valve cover anyways? just it says b18 or b20 on the tag at the front of the block just smudge some grease over it they wont know ---- lol.
11-12-2008, 11:22 PM
#35
Member
Join Date: Mar 2003
Location: toronto, ontario, canada
Posts: 844
no how could you for all they know you blew your engine and put in a new one over night its your car you can do what you want. You dont tell your insurance when you take out a d15 and swap a b20V turbo you just pay for the ---- engine on insurance and take the risk. But besides that I used to get fake etests because when i ran a gsr in the car i had a hollow cat but after i took it out to build it i swaped to a b20 just to have a car to drive and put on a magnaflow high performance cat headers and 2.5 pollished stainless all the way back and I took the chance ran the car legit at crappy tire and it passed with flying colours and they did bump the numbers up because the guy was cool and said ya we can run it as a hot rod because that motor does't belong in the car and i took that same sheet to the ministry with the 2.0 on paper and here i am today with my sticker a happy man. Oh and don't quote me but dont the b20's and the non vtec integra engines have the same looking valve cover anyways? just it says b18 or b20 on the tag at the front of the block just smudge some grease over it they wont know ---- lol.
